Radio - Side Controls
21
22
23
24
25
26
27
External antenna jack (3.5mm)
Volume control
Headphone jack (3.5mm)
Main Tuning knob(push in for
FAST / SLOW / STOP)
Fine tuning / clarify control for SSB
USB Charging port
Radio reset button access hole
Radio-Rear
28
29
30
Whip antenna used for FM, SW and AIR bands
Kickstand
Battery door (18650 battery included)
