Product Functions Overview
•
•
•
•
MCU DB15 Adapter Cable
Multi-PROG OBD Cable
ECU Adapter Multi-PROG Solder Cable
ECU Cable Plug
Plug the cable into the DB44 port of the device, read and write ECU module data
according to the wiring diagram.
Plug the OBD cable into the OBD port of the car, and then select the corresponding
model option on the software to read and write ECU and other module data directly
through the OBD cable.
Plug this adapter cable into the DB44 port of the device, and then connect the
corresponding solder free adapter board to read and write automotive module data.
In order to connect various different types of ECUs, the device has 8 different
types of ECU cable plugs, and the corresponding plugs can be selected to connect
the ECU pins.
•
ECU DB15 Adapter Cable
Plug this adapter cable into the DB44 port of the device, and then connect the
corresponding solder free adapter board to read and write ECU module data.
A
B
C
D
E
F
G
Product Functions Overview
H
•
MCU Adapter Multi-PROG Solder Cable
Plug the cable into the DB44 port of the device, read and write MCU chip data or
automotive module data according to the wiring diagram.
