Chapter 5, Upgrading Your Computer
Page 44
3. Lift the panel toward you and pull it away from the computer.
4. To access the hard drive, remove the screw at the other side and at the top.
5. To access power supply and CPU, remove the screw next to the power
connector Push the power supply straight up and toward you, securing the hard
drive at the back of the computer. Then pull the panel toward you and lift
straight up.
NTower
™
(beige case)
To access the interior of NTower
™
systems equipped with an AMD or Intel
microprocessor, use the following procedure.
1. With the system standing up, face the back of the computer and locate the three
screws on the right side of the back panel.
2. Using a straightedge screwdriver, remove the three screws on the right panel.
3. Pull the panel toward you and pull it away from the computer. You should now
have access to the interior of the computer.
4. To access peripherals (such as the CD/DVD-ROM drive), remove the left
panel of the computer.
MTower
™
(all-beige case)
To access the interior of MTower
™
systems equipped with dual microprocessors,
use the following procedure.
1. With the system standing up, face the back of the computer and locate the two
screws on the right side of the back panel.
2. Using a straightedge screwdriver, remove the two screws on the right panel.
3. Pull the panel toward you and pull it away from the computer. You should now
have access to the interior of the computer.
4. To access peripherals (such as the CD/DVD-ROM drive), remove the left
panel of the computer.
