SYSTEM SPECIFICATIONS
ECU
LED units
Handlebar Control
System Functions!
• Input voltage: 18V - 78V DC
• Main board operating voltage: 9V DC
• Outputs voltage: 12V DC regulated
• Power consumption in standby mode: 14mA
• Heat resistant PVC box
• Dimensions: 50mm (L) x 40mm (W) x 33mm (H)
• Weight: 100g
• Maximum operating voltage: 12.7V
• Maximum output power: 2.1W
• Electronic circuit type: Chip on board
• Colour: Cool White (front units), Amber (rear
units)
• IP66 rated waterproof
• Dimensions: 55mm (L) x 15mm (W) x 3.5mm
(H)
• Headlight switch (ON/OFF), Left/Right turn
switch, horn switch.
• LED monitoring for headlight and turning
signals
• Headlight ON/OFF (headlight sold separately)
• Horn ON/OFF time limited to 1.5sec
consecutive buzz (horn sold separately)
• Left Turn
• Right Turn
• Hazard Lights
