Xiaomi Mi AIoT Router AX3600 User Manual

Power on the router, then connect the Internet (WAN) port
to the DSL/Cable/satellite modem
* If your Internet network is connected via an Ethernet cable at the wall, connect
the Ethernet cable directly to the Internet (WAN) port on the router
Step 1: Connect the cables
English
3
DSL/Cable/
Satellite modem
WAN
LAN
or
Connect
the power
WAN 1 2 3
RESET

Xiaomi Mi AIoT Router AX3600 Specifications

General

Product type	Portable router
Product color	Black
LED indicators	LAN
Internal memory	512 MB
Processor cores	4
Processor model	Qualcomm IPQ8071A
Built-in processor	Yes
Processor frequency	1400 MHz
Processor manufacturer	Qualcomm
Modulation	BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	2402 Mbit/s
Antennas quantity	7
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN interface type	Gigabit Ethernet
DSL WAN	No
Ethernet LAN (RJ-45) ports	3
Security algorithms	WPA-PSK, WPA2-PSK
Mobile operating systems supported	Android
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Power source type	AC

Weight and Dimensions

Depth	408 mm
Width	133 mm
Height	177 mm
