Xinje TH765-M User Manual

TH series Touchscreen User Manual Page 5 of 81 MANUL018R2V1
1-1-2 Control
 Switch control, dynamic monitor and display data, bar map, real time trend map, time trend
map, XY trend map, discrete/continue column map, real time alarm, history alarm record…
 User-defined data collection and saving function
 Set user‟s authority, 9 levels password protection
 Simulate online/offline, upload/download data, configuration function
 USB port inside, connect flash disk to realize data duplication function, speed 480Mbps
 Special USB-B port for data download, make the data transfer faster
 User-defined animation track design
1-1-3 Communication
 Two ports communication independently, can connect two different devices at the same time
 Drive the panel printer directly, economical and flexible
 Support free format communication, user edits the driver program
The work flow of using TH:
Note:
Please use TouchWin V2.C and later version to edit your TH project.
1-2 Work flow
Edit your project
Download project in TH
Do simulate offline
Simulate the TH
action in the
software.
Do simulate online
Connect the PC with
TH, simulate the
action in your PC
Install edit software TouchWin
Connect PC and TH, power on
Connect TH with other devices
Realize communication and data

Xinje TH765-M Specifications

General

Brand	Xinje
Model	TH765-M
Category	Touch Panel
Language	English
