Xinje TH765-M User Manual

TH series Touchscreen User Manual Page 7 of 81 MANUL018R2V1
2-1 TH465-M
Item
TH465-M
Electrical
Input voltage
DC20-DC28V
Consumption
current
130mA
Momentary power
off allowance
Less than 10ms
Withstand voltage
AC1000V-10mA 1 minute ( signal and time )
Insulated
impedance
DC500V- about 10MΩ ( signal and time )
Interface
COM1
Support RS-232/RS-485
COM2
Support RS-232/RS422/RS485
USB1
USB-A ( accord with USB2.0 )
USB2
USB-A ( accord with USB2.0 )
USB3
USB-B ( accord with USB2.0 )
Environment
Operation
temperature
0－50℃
Reserve
temperature
-20-60℃
Environment
temperature
20-85% ( no condensation )
Withstand oscillation
10-25Hz ( X, Y, Z each direction 30 minutes
2G )
Anti-jamming
Voltage noise: 1000Vp-p, pulse 1us, 1
minute
Surrounding air
No corrosive gas
Protection
construction
IP65
Screen
specification
Type
65536 true colours
Screen size
4.3 inch
Use life
More than 50000 hours, 24 hours running
when surrounding temperature is 25 ℃
Resolution
80*272
Contrast
Non-adjustable
Character
Chinese, English, Korean, Japanese…
Character size
Any size and font
Touch panel
4-wire resistance mode
Memory
Screen
8MB
Construction
Cooling method
Natural air cooling
Exterior dimension
150.0*100.0*41.0mm
Mounting dimension
144.0*94.0mm

Xinje TH765-M Specifications

General

Brand	Xinje
Model	TH765-M
Category	Touch Panel
Language	English
