Xinje TH765-M User Manual

TH series Touchscreen User Manual Page 8 of 81 MANUL018R2V1
Item
TH765-M
Electrical
Input voltage
DC20-DC28V
Consumption current
250mA
Momentary power off
allowance
Less than 10ms
Withstand voltage
AC1000V-10mA 1 minute ( signal and time )
Insulated impedance
DC500V- about 10MΩ ( signal and time )
Interface
COM1
Support RS-232/RS-485
COM2
Support RS-232/RS422/RS485
USB1
USB-A ( accord with USB2.0 )
USB2
USB-A ( accord with USB2.0 )
USB3
USB-B ( accord with USB2.0 )
Environment
Operation
temperature
0－50℃
Reserve temperature
-20-60℃
Environment
temperature
20-85% ( no condensation )
Withstand oscillation
10-25Hz ( X, Y, Z each direction 30 minutes 2G )
Anti-jamming
Voltage noise: 1000Vp-p, pulse 1us, 1 minute
Surrounding air
No corrosive gas
Protection
construction
IP65
Screen
specification
Type
65536 true colors
Screen size
7 inch
Use life
More than 50000 hours, 24 hours running when
surrounding temperature is 25 ℃
Resolution
800*448
Contrast
Non-adjustable
Character
Chinese, English, Korean, Japanese…
Character size
Any size and font
Touch panel
4-wire resistance mode
Memory
Screen
128MB
Construction
Cooling method
Natural air cooling
Exterior dimension
205.0*151.5*48.9mm
Mounting dimension
192.0*138.5mm
2-2 TH765-M

Xinje TH765-M Specifications

General

Brand	Xinje
Model	TH765-M
Category	Touch Panel
Language	English
