Xinje TS Series User Manual

2
(3) Communication
◆ Dual port independent communication, which can connect multiple different devices at the same time.
◆ -E series is equipped with Ethernet interface to support communication with Ethernet equipment,
Siemens S7-1200, Siemens S7-200 Smart and other Modbus TCP equipment.
◆ The printer can be directly driven, which is economical and flexible.
◆ Support free format communication, and end users can write drivers freely.
1-1-2. Naming rule
①
③
②
700
TS3
E
①：
Series
TS3 series
②：
Display
700：7.0 inch
1000：10.1 inch
③：
Interface
M：USB-B, USB-A, COM1, COM2
E：USB-B, USB-A, RJ45, COM1, COM2
1-1-3. Model list
Xinje TS3 series HMI have the following models according to different display sizes and function types:
Display
7〞
10.1〞
General model
TS3-700-M
TS3-700-E
TS3-1000-M
TS3-1000-E
1-2. Product specification
Product model
TS3-700
TS3-1000
Product
features
Size
7.0”
10.1”
Resolution
800*480
1024*600
LCD
TFT LCD display, LED
Display colors
16.77 million colors
Brightness
200 cd/m
2
Touch panel
Four wire resistive touch screen
LCD life
More than 50000 hours, ambient temperature 25℃, 24-hour operation
Processor
Cortex-A8 600MHz
Storage
128MB
Interface
COM1
RS232/RS485
COM2
RS232/RS485/RS422
USB-A port
Flash disk port, USB2.0
USB-B port
USB download port, USB2.0
Ethernet port
Standard RJ45 (10/100M self-adaption), -E models support
Electrical
characteristics
Input voltage
DC24V (voltage range: DC22V-DC26V)
Current
consumption
200mA
270mA
Allowable
power loss
Below 10ms (the actual power loss is less than 1s)

Xinje TS Series Specifications

General

Brand	Xinje
Model	TS Series
Category	Touch Panel
Language	English
