V5 series inverter
39
tion 1: Enabled
P3.04 AVR function 0: disabled
1: enable all the time
2: Disabled when decelerating
1 0 ×
P3.05 Slip frequency compen-
sation
0~150%
1% 0%
×
P3.06 Jog frequency 0.10~50.00Hz 0.01Hz 5.00Hz ○
P3.07 Accelerate time of jog 0.1~60.0s 0.1s 5.0s ○
P3.08 Decelerate time of jog 0.1~60.0s 0.1s 5.0s ○
P3.09 Communication
configuration
LED lowest bit: baud rate
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
LED ten bit: data format
0: 1-7-2 foramt, no parity
1: 1-7-1 format, Odd
2: 1-7-1 format, Even
3: 1-8-2 format, None
4: 1-8-1 format, Odd
5: 1-8-1 format, Even
6: 1-8-1 format, None
(When use Modbus-RTU communica-
tion mode, please select data mode
3~6)
LED hundred bit: undefined
1 054 ×
P3.10 Inverter address 0~248
0: broadcast address
248: inverter as the host address
(function is developing)
1 1 ×
P3.11
Communication timeout
detect time
0.0~1000.0s
0.0: Detection disabled
0.1s 0.0s ×
P3.12 Inverter answer delay 0~1000ms 1 5ms ×
P3.13 Proportion of communi-
cation frequency
0.01~1.00 0.01 1.00 ×
P3.14 Accerlate time 2 0.1~6000.0 0.1 10.0 ○
P3.15 Decerlate time 2 0.1~6000.0 0.1 10.0 ○
P3.16 Accerlate time 3 0.1~6000.0 0.1 10.0 ○
P3.17 Decerlate time 3 0.1~6000.0 0.1 10.0 ○
P3.18 Accerlate time 4 0.1~6000.0 0.1 10.0 ○
P3.19 Decerlate time 4 0.1~6000.0 0.1 10.0 ○
P3.20 Accerlate time 5 0.1~6000.0 0.1 10.0 ○
P3.21 Decerlate time 5 0.1~6000.0 0.1 10.0 ○
P3.22 Accerlate time 6 0.1~6000.0 0.1 10.0 ○
P3.23 Decerlate time 6 0.1~6000.0 0.1 10.0 ○
P3.24 Accerlate time 7 0.1~6000.0 0.1 10.0 ○
