V5 series inverter
49
PA.05 Poles of motor 2~48 1 Dependent on in-
verter’s model
×
PA.06 Stator inductance of motor 0.1~5000.0mH 0.1mH Dependent on in-
verter’s model
×
PA.07 Rotor inductance of motor 0.1~5000.0mH 0.1mH Dependent on in-
verter’s model
×
PA.08 Mutual induction of stator and
rotor
0.1~5000.0mH 0.1mH Dependent on in-
verter’s model
×
PA.09 Stator resistance of motor 0.001~50.000Ω 0.001Ω Dependent on in-
verter’s model
×
PA.10 Rotor resistance of motor 0.001~50.000Ω 0.001Ω Dependent on in-
verter’s model
×
PA.11 Over current protection coeffi-
cient of torque current
0~15 1 15 ×
PA.12 Proportion adjustment coeffi-
cient of speed loop
50~120 1 85 ×
PA.13 Integral adjustment coefficient
of speed loop
100~500 1 360 ×
PA.14 Vector torque boost 100~150 1 80 ×
PA.15 Reversed 0 0 0 ×
PA.16 Reversed 1~5 1 4 ×
PA.17 Excitation 100~150 1 100 ×
PA.18 Slip compensation factor 150 1 150 ×
PA.19 Reversed 0~2 1 0
12. Special Application parameters (Group PB)
Group PB: Special Application parameters
Parameter Name Range Minmum unit
Default
setting
Change
PB.00 Jog frequency source 0~4
0: P3.06
1: Panel potentiometer
2: P0.02
3: VI
4: CI
0 0 ○
PB.01 selection of forward/
reverse dead time
0: Dead time is enabled (Min 0.1s)
1: dead time can be set to 0 (set
P0.05=0.0S, P0.20≥0.5Hz )
1 0 ○
PB.02 Inverter type selection 0: G type(normal)
1: P type(wind machine,water pump,
power improves 1 level)
Note:if set to 1, P0.22 must set to 3
1 0 ×
PB.03 Short the run terminal
before power on and set
the run mode
0: after inverter is power on, run im-
mediately
1: after inverter is power on, cut off
the terminal and connect again then
run
1 1 ×
