V5 series inverter
60
When P0.01（Frequency setting chanel）= 8, set the frequency setting channel combination via P3.00.
0: VI＋CI
1: VI－CI
2: External pulse ＋VI＋Increase/Decrease key
3: External pulse－VI－Increase/Decrease key
4: External pulse＋CI
5: External pulse－CI
6: RS485＋VI+Increase/Decrease key
7: RS485－VI－Increase/Decrease key
8: RS485＋CI+Increase/Decrease key
9: RS485－CI-Increase/Decrease key
10: RS485＋CI＋External pulse
11: RS485－CI－External pulse
12: RS485＋VI＋External pulse
13: RS485－VI－External pulse
14: VI＋CI＋Increase/Decrease key＋Digital setting P0.02
15: VI＋CI－Increase/Decrease key＋Digital setting P0.02
16: MAX (VI, CI)
17: MIN (VI, CI)
18: MAX (VI, CI, PLUSE)
19: MIN (VI, CI, PLUSE)
20: VI, CI is avalid, VI is priority
P3.01 Parameter initialization lock
Range: lowest bit 0~2, ten bit ~2
00
LED lowest bit:
0: All the parameters can be modified.
1: other parameters cannot be modified except this parameter.
2: Only P0.02 and P3.01 can be modified.
LED ten bit:
0: invalid
1: Restore to default setting
2: Clear fault record
Note: (1) The default setting of P3.01 is 0 and allows all the parameters to be modified. Please set it to 0 before you want
to modify function code. If it is need to protect the parameters, please set this parameter to required protection
level.
(2) P3.01 will be changed to 0 automatically after restoring to default setting.
P3.02 Parameter copy (this function is developing) Range: 0, 1, 2 0
0: Disabled
1: Parameter upload: Upload the parameters from inverter to remote opration panel.
2: Parameter download: Download the parameters from remote operation panel to inverter.
Note: This function is still in developing.
P3.03 Auto energy-saving running Range: 0, 1 0
0: Disabled
1: Enabled
Inverter can saves the energy through detecting the load current; adjust output voltage when motor has no load or light load
running. This function is used to the situation of stable load and speed.
P3.04 AVR funciton Range: 0, 1, 2 0
