43
Profile dimension 63mm×102mm×73.3mm
MA-8AD-A/V
Item Voltage Current
DC0～5V、0～10V DC0～20mA、4～20mA
Analog input range
( exterior load resistor
2KΩ~1MΩ)
( exterior load resistor less than
500Ω)
Maximum input range ±18V 0～40mA
Digital output range 12 bits binary numbers
Resolution 1/4095（12Bit）
Integrated precision 0.8%
Conversion speed 20ms per channel
Power supply for analog DC24V±10%，100mA
Installation Use M3 screw or fix on DIN46277 rail ( width 35mm )
Profile dimension 63mm×102mm×73.3mm
MA-4AD
Item Analog input (4AD)
Analog input type Voltage input Current input
Analog input range 0~5V,0~10V 0~20mA,4~20mA
Maximum input range DC±18V 0~40mA
Digital output range 12 bits binary value (0~4095)
Resolution 1/4095(12Bit)
PID output range 0~K4095
Integrated precision 0.8%
Converting speed 20ms per channel
Power for analog DC24V±10%，100mA
Installation Fix up the module with M3 screw or put on DIN46277 rail (width 35mm)
Profile dimension 63mm×102mm×73.3mm
MA-4AD2DA
Item Analog input ( 4AD ) Analog output ( 2DA )
Voltage input Current input Voltage output Current output
Analog input range 0~5V,0~10V 0~20mA,4~20mA -
Max input range DC±18V 0~40mA -
Analog output range -
0~5V、0~10V,
( exterior load
resistor 2KΩ~1MΩ)
0~20mA、4~20mA
(exterior load resistor
less than 500Ω)
