4 Quick Start Guide
4.1 Device Wakeup
To start up the device, simply hold the black button located near the circular connector on the
side panel of the device for 3 seconds. You should see the blue “C” LED light up and then fade out.
The blue LED will blink when the device is successfully connected to the network. Refer to table
in section 2.3 for LED behavior.
Note: The factory default settings are configured to have the device to sleep within 2 minutes of
wake. Consider pulling the IN1 wire high to keep the device awake for configuration purposes or
disable sleep by issuing the proper 3017 command.
