Xirgo Technologies XT4970D - Hardware Description

5
2 Hardware Description
Below is a depiction of key interfaces of the XT4970D:
The Associated Cable Harness that interfaces with the unit is shown below:
Solar Panel
Device/FCC Label
Wake-up/
ZigBee Pairing
Button
Zigb
8-Pin Bayonet
Connector
LED Indicators
