Xirrus X2 Series User Manual

X2 and XD2 Two-Radio Access Points
6
Using the Reset Button
The reset button returns the AP to factory default settings while rebooting. It is
located on the bottom of the unit. Use the reset button as follows:
 Unplug the cable from the GIG1/POE port.
 Press the reset button all the way (there should be a faint click) and hold it.
 Plug the cable back in and continue to keep the button pressed for 10 seconds.
This triggers the factory default reset during the boot process.
Specifications and Drawings
Physical/Environmental Specifications
 Dimensions (WxDxH, including mounting plate): 8 x 8 x 2.25 in / 20.3 x 20.3 x 5.7 cm
 Weight: 2 lb / 0.9 kg
 Operating Temperature: 0-50°C / 32-122°F, 5-95% humidity, non-condensing.
Mounting Plate
6
7
