wiring schematics
NOTE: This grill uses a transformer to provide power to the LED lights and work lights.
The transformer should be secured to the island walls or cart back wall. Plug only into a
Ground Fault Interrupter (GFI) protected circuit.
wiring schematics
NOTE: On install the electrical transformer to the cart use the 4 Bolts provided in your
hardware pack. The transformed has 4 holes that will match up to the holes on the back
panel of the cart. face the transformer main electrical wire "facing down" and the wire from
the gas grill will connect securely into the top of the transformer making a watertight fit.
Do not store a spare LP-Gas tank under or near
this appliance. Never fill the tank beyond 80
percent full; and if the information is not followed
exactly, a fire causing death or serious injury
may occur.
!
WARNING
!
