Connecting to a TV
NOTES:
l
l
l
l
Turn off all devices before connecting
Select CVBS, S-Video, SCART or VGAoutput according to differentT s.
Follow the sketch above to connect the devices with selected output
Refer to setup instructions on the page 18,19
V
SCART
STEREO OUTPUT LEFT
S-VIDEO OUTPUT
CVBS VIDEO OUTPUT
STEREO OUTPUT RIGHT
CONNECTIONS
English
SCART
VGA OUTPUT
