Xoss NAV User Manual

- 5 -
NAV- Smart GPS Cycling Computer
Rubber Band
Protection Rubber Pad
Cycling Computer Mount
Type-C USB Cable
User Manual
×1
×2
×1
×1
×1
×1
Packing List
NAV×1 Cycling Computer Mount×1
Type-C USB Cable×1
Protection Rubber Pad×1
Rubber Band×2
User Manual×1
用户手册
辰-智能GPS码表
-简体中文-
① Put the rubber pad on the back of the bike stand;
② Use a rubber band to secure the bracket to the handlebar or stem;
③ Align the tabs on the back of the device with the grooves on the bike stand, press down
slightly, and rotate the device 90 degrees until it locks into place.
Rubber Band
Mount
Handlebar
Cross tie the base with a rubber band Install the Cycling Computer
Installation

Xoss NAV Specifications

Operating Environment

operating temperature	-10℃ ～ 50℃
waterproof	IP×7

Battery

endurance time	Up to 33 Hours
battery capacity	600mAh
battery type	Rechargeable Lithium Ion

Connectivity

wireless transmission	ANT+/Bluetooth

Weight and Dimensions

size	88mm × 55mm × 19mm
product weight	59g
