Xpresskit PKH34 - INSTALL “A”: Honda & Acura Type “C” Transponder Data Override Interface

1
6
5
4
3
2
7
ECM Side
Section A
System
Remote Control
page 1 to 2
Red Green
Violet
Black
Violet/White
Pink Pink/White
Chassis Ground
Brown
(-) Ground When Running (status)
INPUT INPUT INPUT
(-)
(+)
(-)
Ignition
(+)
INPUT
Orange
N/C
N/C N/C
(+)
Security Light - ECM Side
OUTPUT
(+)
N/C
N/C
N/C
DATA
Data
INPUT
(+)12 Volt Constant
WIRE SIDE OF CONNECTOR
Blue
N/C
INSTALL “A”: Honda & Acura Type “C”
Transponder Data Override Interface
Security Light - Key Side
Key Side
HONDA
N/C N/C
+12VD
C
4 PIN DATA TO DATA (D2D) CABLE
MODEL: PKH34
Rev.: 20110106
© 2008 Directed Electronics. All rights reserved.
