INSTALL “B”: Honda & Acura Type “D”
Transponder Data Override Interface
Red
Green
Violet
Black
Violet/White
Pink
Pink/White
Chassis Ground
Brown
(-) Ground When Running (status)
INPUT
INPUT
INPUT
(-)
(+)
(-)
Orange
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
DATA
Data
(+)12 Volt Constant
WIRE SIDE
OF CONN.
Blue
N/C
N/C
N/C
N/C
N/C
N/C
+12V
DC
4 PIN DATA TO DATA (D2D) CABLE
System
Remote Control
1 654327
Light Green
Data Wire
Section A
See Wire Connection Guide for detailed information regarding wire functionality
HONDA
Connect Violet wire from
module to Data wire
accordning to your vehicle.
See vehicle wiring reference
chart on next page.
MODEL: PKH34
Rev.: 20110106
© 2008 Directed Electronics. All rights reserved.
