2.3 Printer Parts
2.3.1 Front View
2.3.2 Rear View
Note: The interface picture here is for reference only. Please refer to the product specification for
the interfaces availability.
5
1
Top Cover
Label Outlet
Front Panel
LED Indicator
Feed Button
Clear Window
Cover Open Lever
1. Power Switch
2. SD Card
3. Power Jack
4. USB Interface
5. RS-232C DB-9 Interface
2
3
4
5
