49
902310
SH M3x10
960030
N M3
GTX8
12. FINAL ASSEMBLY
WHEEL NUTS
#355261 OPEN INCLUDED
#293560 COVERED OPTION
#355265 COVERED OPTION
Wheel & Tire
(NOT INCLUDED)
Wheel & Tire
(NOT INCLUDED)
4x
902325
SH M3x25
To tighten the screw you can also use the
#107570 HUDY 17mm Wheel Nut Tool
Cut off remaining
material
Cut off remaining
material
➐
approx. 52mm
approx. 37mm
NOTE
ORIENTATION
NOTE
ORIENTATION
DETAIL
NOTE
ORIENTATION
901306
SB M3x6
901306
SB M3x6
