8
Re-install all shocks
(front and rear)
FILLING AND INSTALLING THE SHOCK ABSORBERS
Re-install each shock absorber, fi ll each shock absorber with the supplied shock oil, and install on the micro nitro truck.
RE-INSTALLING THE SHOCKS
FILLING THE
SHOCKS
INSTALLING THE SHOCKS
INSTALL ALL SHOCKS
(front and rear)
INITIAL POSITIONS
Re-install shock collar and
spring from each shock (front
and rear)
Unthread the shock cap from
the shock body and remove
the shock membrane.
Thread the shock cap onto
the shock body. Excess oil
should spill out.
Pull down
the piston
Fill until shock oil
nearly overfl ows
Gently move the piston
up and down to get rid
of air bubbles
Pull down
the piston
OIL
Insert clips according
to track conditions
Remove clips
To Next Page
