REAR CAMBER RISE
REAR ROLL CENTER
DETAIL
STEP DETAIL
DETAIL
Tighten fully
setscrew M3x6 onto atspot
2x
2mm
903308
SFH M3x8
903308
SFH M3x8
902310
SH M3x10
903412
SFH M4x12
940508
BB 5x8x2.5
903416
SFH M4x16
901303
SB M3x3
981208
P 2x8
BEARING
OIL
3x8
3x8
4x16
4x16
4x12
4x12
INITIAL SETTING
2. REAR SUSPENSION
Use 0mm suspension holders for initial assembly
NOTE ORIENTATION
Composite set of bushings
