16
BELT TENSION
ADJUSTMENT
VIDEO TECH TIP
▶
903306
SFH M3x6
903305
SFH M3x5
962042
S 4x6x0.1
0.1mm
3. CENTRAL TRANSMISSION
NOTE
ORIENTATION
