Xray X4F - Page 27

27
CAMBER & UPPER
ARMS
VIDEO TECH TIP
▶
902304
SH M3x4
REAR TRANSMISSION
REAR
REAR
FRONT TRANSMISSION
FRONT
FRONT
2x
2x
2x
2x
2x
2x
VIEW
VIEW
NOTE
ORIENTATION
NOTE
ORIENTATION
VIEW
VIEW
with flat area
with recessed area
VIEW
VIEW
29.5mm
26.2mm
Check arm orientation so that each arm is in
the correct location with the markings facing
down when installed.
Check arm orientation so that each arm is in
the correct location with the markings facing
down when installed.
24.6mm
31mm
2.0 mm
2.0 mm
Push inside
Push inside
Tighten
Apply Graphite Grease
Apply Graphite Grease
Tighten
5. FRONT & REAR SUSPENSION
NOTE ORIENTATION
Shiny side
Ball joint should be aligned
in the arm with the shiny side
facing down.
Shiny side
Cut out
Ball joint should be aligned
in the arm with the machined
clearance facing down.
NOTE ORIENTATION
