REAR BODY POST
MOUNTING
VIDEO TECH TIP
▶
OPTION
BODY STOP SYSTEM
The X4F features an adjustable front body upstop system incorporated into the new
upper arm to prevent the body shell from bottoming out and hitting the ground during
cornering. When the system is set correctly, it allows the body to be run lower without
dragging on the ground to improve aerodynamic efficiency.
BODY STOP ALTERNATIVE
with screw and ball joint
(#901308 SB M3x8mm / #303457 Ball Joint)
BODY STOP ALTERNATIVE
with screw
(#902316 SH M3x16mm)
(NOT INCLUDED)
(NOT INCLUDED)
