903308
SFH M3x8
902316
SH M3x16
2x
1x
#293101
HUDY ALU RC FAN 30MM
SIDE MOUNT 2 HOLE
#293112
HUDY BRUSHLESS RC FAN 30MM
WITH INTERNAL SOLDERING TABS
#293110
HUDY BRUSHLESS RC FAN 30MM
WITH EXTERNAL SOLDERING TABS
42
DIRTCARPET
7. FINAL ASSEMBLY
FAN ASSEMBLY BEHIND MOTOR
FAN ASSEMBLY BETWEEN BATTERY & MOTOR
Centering pin
Centering pin
ALTERNATIVE 1
ALTERNATIVE 2
