Settings Menu
To enter in the settings menu, keep pressed TARE + ZERO keys for 3 seconds, display shows Cod0000.
TARE : scroll the numbers or chose the parameters
PRINT : change position
ZERO : confirm and enter in the next step.
Code
Mark display
Description
Setting range
Cod 0001
Zero – x.x
Zero range
0.0 d – 6.0 d
Stdy - x.x
Start sensitive range
0.0 d – 6.0 d
Sens – x
Inner sensitivity grade
1,2,3,4,5,6
Filt – x
Stability Filter
1,2,3,4,5,6,7 -- 1 weakest – 7 strongest
Speed
Weighing speed
1,2,3 -- 1 slow - 3 fast
BL – xxx
Backlight
On, Off, AUTO
BEPxxx
Beeper
On, Off
ModRec
Function mode
0: switch on always in normal mode
1: switch on in the last weighing mode used
Tadj
Display temperature
-1.9 to +1.9
Baud xx
Baud rate
12; 1200; 24; 2400; 48; 4800; 96; 9600.
Con – xxx
Communication
NON: no communication
CON: continuous
STY: print when stable
KEY: print when press PRINT key
SOFT: software exchange
Txxx: timing print, xxx is the time set, in sec
BLANk
Output the blank line
Line 0,1,2,3,4,5,6,7,8,9
Cod 0002
Unit - xxx
Unit on display
On, Off
Software Exchange
List of command which the communicating device can send in software exchange mode. (ASCII code)
No.
Command
Function
1
?
Sample
2
P
Print
3
T
Tare
4
Z
Back to Zero
5
U
Unit
