Page 44
STEP 39: STEERING LINKAGE
(148558) Lock Nut 3mm -- 1
Servo Arm
Included with Servo
(149333) Threaded Stud 3 x 16mm -- 1
(148635) Button Head Screw 3 x 18mm -- 1
(148560) Flanged Lock Nut 3mm -- 1
(148634) Button Head Screw 3 x 12mm -- 1
148634
149333
149731
149333
149312
148558
149333
148635
148560
Step 38
Retaining Screw
Included with Servo
ExpLODED vIEW ASSEmBLY DRAWINGS
Continued On Next Page
To Next Page
