targets are no substitute for testing and regular inspection of the gearbox
internals.
Component life is affected by the precise application and can be influenced by
circuit layout and conditions as well as driver style. Many of the components
stated above with a maximum 'typical' life of 6000km may be found to perform
successfully for extended mileage however extended running above 6000km is
done at a customer's risk.
Table 2 - Typical Component Life Ratings
Component
(km)
Clutch Shaft 1500 3000 6000
Layshaft (Integral 1
st
/ 2
nd
gear
ratio set) 1500 3000 6000
3
rd
Gear Ratio (hobbed) 500 1000 2000*
3
rd
Gear Ratio (ground) 1500 3000 6000
4
th
– 6
th
Gear Ratios 1500 3000 6000
Dog Rings 1500 3000 6000
Layshaft / Mainshaft Nuts 1500 3000 6000
Gearchange Barrel 1500 3000 9000
Selector Forks 1500 3000 9000
Mainshaft 1500 3000 9000
Mainshaft Hubs 1500 3000 6000
Reverse Idler / Mainshaft Gears 1500 3000 9000
Detent Plunger 1500 - 9000
Detent Spring - - 6000
Oil Pump Rotors 1500 3000 6000
Oil Filter 1500 - 6000
Spiral Bevel Set 1500 3000 6000
Differential End Cap & Body 3000 3000 9000
Friction Plates 3000 - 6000
Side Gears 3000 3000 6000
Pinion Mates 3000 3000 6000
Side Gear Rings 3000 3000 9000
Cross Pin 3000 3000 9000
Output Flanges 1500 3000 6000
All Bearings 3000 - 6000
All K-nuts, O-rings & Seals Fit new when removed
Gearbox Oil Drain and replace oil every 1500km
1254-932-000A Actuator
See separate 1254 manual
*See technical bulletin 1152-0003.
