Xtracer 1152 - Appendix A - Non Standard Tightening Torques

Issue 2.0 – 10/12/15 - 1152 Longitudinal Transaxle Sportscar Gearbox Manual
© 2015 - Xtrac Limited, Gables Way, Kennet Park, Thatcham, Berkshire. RG19 4ZA.
Xtrac Inc, 6183 W. 80th Street, Indianapolis, IN 46278. United States
25
7. Appendix A – Non Standard Tightening Torques
Description
Location
(Sub-assembly)
Torque Comments
Pinion Nut
(1152-475-001A)
1152-901-000A
400Nm
(295 lbf ft)
Oil Threads
Gearchange Barrel Nut
(105-432-002A)
1152-902-000A
68Nm
(50 lbf ft)
Loctite 648
Differential Lid
(600-449-001A)
1152-949-000A
230Nm
(170 lbf ft)
Oil Threads
Layshaft Nut
(199-421-006A)
1152-996-000*
136Nm
(100 lbf ft)
Oil Threads
Mainshaft Nut
(099-422-006B)
1152-996-000*
136Nm
(100 lbf ft)
Oil Threads
