Gearbox Type: 1152B
- LMP3
1
st
/ 2
nd
(Integral Layshaft)
1152-42M-000A*
*= Layshaft Set Code e.g. 1152-42M-000AA
(1152-421-000A* / 033-422-008A)
( / 033-422-008A)
Code(*)
Input
Output
Sum
Ratio
Input
Output
Ratio
A
13
37
50 2.846
15
34
2.267
233-42M-3A
(Hobbed)

(233-421-003A / 033-422-008A)
233-42M-3B
(Ground) 
(233-421-003B / 033-422-008E)
Input
Output
Sum
Ratio
13
23
36
1.769

17
30
47 1.765 
195-42M-4A
(195-421-004A / 033-422-008A)
Input
Output
Sum
Ratio
19
28
47 1.474
19
24
43 1.263
23
25
48 1.087
Input
Output
Sum
Ratio
11
31
42 2.818
49
Sum
Collared 3
rd
4
th
– 6
th
27/10/2015
Date
Final Drive
Issue
6
Approved
MBB
Note: Ratings charts (pages 3&4) supplied in accordance with ISO6336-2006 & are based on an engine speed of 7000RPM and torque of
540Nm. (Rating values are comparative, a higher value means that a gear is comparatively stronger or has more resistance to pitting than
a lower value. Where possible, always select a gear with the highest values. The gear width is taken into account when the rating is
calculated.)
120-1152-001
Drg
Tony Collinson
Drawn
1
st
2
nd
Xtrac reserve the right to change ratios without notice.
