Gearbox Type: 1152B
- LMP3
Date ApprovedDrawn Drg Issue
Tony Collinson 120-1152-001 27/10/2015 MBB 6
13:37
15:34
13:23
17:30
19:28
19:24
23:25
0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80
Safety Factor (SF)
Bending Safety Factors (for comparison purposes)
Input Gear Output Gear
Key
1
st /
2
nd
Gear
Torque
Nm
540
3
rd
Gear
4
th
- 6
h
Gear
Minimum Safety Factors Shown For Selected Ratios
Xtrac reserve the right to change ratios without notice.
