Xtralis VESDA LCD Programmer Product Guide Xtralis VESDA
®
14 www.xtralis.com
10. Select Events - This function assists in easier viewing of the logged events. The
events can be sorted as per the categories displayed. After selecting the events,
proceed to Screen 9 to view the events.
• End Date - This allows viewing of events up to the date mentioned in the date
field. You can input the required date in the date field.
• End Time - This is the time up to which events will be displayed for viewing. You
can input the required time in the time field.
• Events to view -
- Smoke Level - A against Smoke Level will display logged smoke levels
- Alarms - A against Alarms displays a log of alarms
- Faults - A against Faults displays a log of the logged faults
- User Action - To view a log of user actions place a against user action
- Clear Log - This function is only available with DST access.
To clear the log of events highlight Start and press .
Use the + key to place a
and - key to insert a X and deselect the option.
ADM
11. Zone Control - The four functions under Zone/Address control are the same as
the functions performed by the buttons on the display module.
• Mode - This controls the mode of the Multi-Segment LCD display on any display
connected to that zone. Use the +, -, and the keys to change the mode
- Sensitivity - Displays the sensitivity level of Fire 1
- Smoke - Displays the current smoke level
- Address Number - Displays the assigned Address number for the detector
• Silence - Silences the beeping sound of the detector
• Reset - Resets fire and fault conditions
• Isolate - Starts and stops isolation of the detector
USR
12. Smoke Thresholds - This screen lists screens 13 to 19 as options available for
setting smoke thresholds.
ADM
13. Day Thresholds - This screen allows viewing and changing the current Fire 2, Fire
1, Action and Alert thresholds for day time.
ADM
Scrn
No.
Description
Min.
Access
Level
↵
↵
Parameter Default Minimum Maximum
Fire 2/Full Scale 2.000% obs/m 0.020% obs/m 20.000% obs/m
(0.625% obs/ft) (0.0062% obs/ft) (6.25% obs/ft)
Fire 1/Fire 0.200% obs/m 0.015% obs/m 2.000% obs/m
(0.0625% obs/ft) (0.0046% obs/ft) (0.6250% obs/ft)
Action/Pre/
Alarm
0.140% obs/m 0.010% obs/m 1.995% obs/m
(0.044% obs/ft) (0.0031 obs/ft) (0.6234% obs/ft
Alert 0.080% obs/m 0.005% obs/m 1.990% obs/m
(0.025% obs/ft) (0.0015% obs/ft) (0.6218% obs/ft)
