Xtralis VESDAnet - Testing the Installed VESDAnet Interface Card

8 www.xtralis.com
VESDAnet Interface Card Product Guide Xtralis VESDA
®
Testing the Installed VESDAnet Interface
Card
The VESDAnet Interface Card uses LEDs to signify certain conditions.
Table 1 - VESDAnet Interface Card LED Indicator key
To test the card:
1. Apply power to the VLF.
2. View green Power LED and flashing SYS OK LED on the card.
3. View amber DET LED lit.
4. View amber LEDs lit corresponding to correct Port A and B connections
to the next device.
Using a VESDAnet tool such as VSC, or LCD Programmer, you can now view
and configure the VLF detector via VESDAnet.
LED Color Status
Power Green Is lit when power is supplied to the card
SYS OK Amber Is flashing when the card’s processor is running
VN A Amber Is lit when the card is communicating on
VESDAnet Port A
VN B Amber Is lit when the card is communicating on
VESDAnet Port B
DET Amber Is lit when the card is communicating with the
detector.
