INSTALLATION
Do not submerge this product in water. The pressure lter should be used in-line, between a pump and
a water feature or waterfall. The lter can also be partially buried to help disguise it in your garden.
Place the lter on a rm and level base, e.g. on a slab. Please make sure that there is unhindered
access to the lid in order to be able to carry out maintenance on the lter.
When the lter is being used at ‘lter’ mode, the cleaning connection or any drainage hose connected
to it must always be sealed with the sealing cap and inserted at seal in order to prevent the pond
from emptying. At the same time the sealing cap acts as a safe guard in case the function switch is
accidentally set to ‘clean’.
Make sure the Function switch is always set to ‘Filter’ when the pump is in operation. The Function
switch may only be set to ‘Clean’ when cleaning the lter sponges with the handle function. Before
starting up the lter check that the hoses, sealing cap and tension rings are sitting correctly. Never lter
any liquids other than water. Keep the lter out of direct sunlight.
DIAGRAM
A. WATER INLET: The pump is connected to the water inlet with a pressure hose.
B. VORTEX SYSTEM: Suspended matter and bio-sludge are precipitated by the centrifugal affect and
gravity.
C. MECHANICAL FILTER: Dirt particles are trapped by the outer surface of the lter sponges before
the water ows the entire height of the lter from the edge into the inner chamber of the lter.
D. BIOLOGICAL CLARIFYING: The yellow and blue lter sponges differ in size and density. This
creates zones where the water can ow at different speeds.
E. PRE-CLARIFYING POND WATER: As the water
ows out it is briey exposed to ultraviolet radiation
under the UVC lamp. This kills off germs and bacteria
and inhibits algae growth.
F. WATER OUTLET WITH FLOW INDICATOR: At
the water outlet the claried water is fed back into the
garden pond via pressure hose or a watercourse etc.
G. CLEANING CONNECTION: When cleaning the lter a drainage
hose an be connected to the cleaning connection which diverts the
dirty water into the sewage system or into a owerbed.
H. FUNCTION SWITCH: The Function Switch is used to switch
between normal water discharge into the pond lter and the cleaning
connection “Clean” and press it to wash the lter sponge.
I. TURBIDIMETER: If the lter sponge is too dirty, the Turbid will go from green to yellow. This means the
sponge needs to be washed out.
CLEAR WATER: Clear water is achieved if the sh or stones can be seen at the bottom of the pond at a
depth of 1m.
