Operator Cab
Operation Manual 38
I. REAR AXLE LOCKED
The Rear Axle Locked Indicator illuminates when the forklift
is in the axle lock mode. The rear axle locks when the parking
brake is set to ON (engaged), or the transmission is in NEUTRAL
or the service brake is applied, and when the boom is above
10. If the Rear Axle Locked Indicator does not illuminate
when the forklift is in the axle lock mode, stop the forklift,
follow proper shut down procedures, tag forklift with “Do Not
Operate” tags, and have a qualied mechanic service or repair
the forklift BEFORE placing it into service again.
J. REAR AXLE CENTERED
The Rear Axle Centered Indicator will be displayed when the
rear wheels are aligned perpendicular to the rear axle. The rear
wheels should be centered before changing steering modes.
L. TACHOMETER
The Tachometer indicates engine RPM using a 0-2500 RPM an-
alog dial and also using digital RPM readout at the bottom of
the tachometer display
M. HOURMETER
The Hourmeter indicates and records engine operating
hours. Use the Hourmeter to establish a forklift maintenance
schedule.
N. DEF GAUGE / LOW DEF LEVEL INDICATOR
The DEF Gauge indicates the quantity of uid in the Diesel
Exhaust Fluid (DEF) tank. The total capacity of the DEF tank is
5 gallons. The DEF tank should be lled after every fuel rell.
DEF should be added when the Low DEF (Diesel Exhaust Fluid)
Level indicator is displayed. Refer to the Operation section
on Warning Indicators and Fault Codes and the Engine
Indicator Chart (Fig. 69).
O. ENGINE TEMP GAUGE AND HIGH TEMP INDICATOR
The Engine Temp Gauge indicates the temperature of the
coolant in the engine cooling system. After starting the fork-
lift, allow time for the Engine Temp Gauge to begin moving
before operating the forklift. After the engine has suciently
been warmed up, normal engine coolant temperature should
read between 180 to 200 F.
P. VOLTAGE GAUGE
The Voltage Gauge indicates the amount of charge (in Volts).
Normal system voltage is between 12.5 and 14 Volts. If the
voltage gauge shows abnormal readings, stop the forklift,
follow proper shut down procedures, tag forklift with “Do Not
Operate” tags, and have a qualied mechanic service or repair
the forklift BEFORE placing it into service again.
Q. FUEL GAUGE AND LOW FUEL INDICATOR
The fuel gauge indicates the approximate quantity of fuel in
the tank. The total capacity of the fuel tank is 72 gallons.
A. HIGH HYDRAULIC OIL TEMP
The hydraulic oil temperature indicator illuminates when the
oil temperature is above 180 F (82 C). If the hydraulic oil
temperature indicator illuminates, stop and idle the engine
to allow time for cooling. If the hydraulic oil temperature
indicator does not go out after ve (5) minutes, stop the forklift,
follow proper shut down procedures, tag the forklift with “Do
Not Operate” tags, and have a qualied mechanic service or
repair the forklift BEFORE placing it into service again.
B. WATER IN FUEL
The Water in Fuel Indicator will be displayed when water is
detected in the fuel lter. Drain the water by opening the
petcock on the bottom of the fuel lter.
C. LOW BRAKE PRESSURE
The Low Brake Pressure indicator illuminates if the hydraulic
oil pressure gets too low. If the Low Brake Pressure indicator
is illuminated, do not release the parking brake or engage
transmission until the indicator is out. If the indicator does not
go out, stop the forklift, follow proper shut down procedures,
tag forklift with “Do Not Operate” tags, and have a qualied
mechanic service or repair the forklift BEFORE placing it into
service again.
D. LOW OIL PRESSURE
The Low Oil Pressure Indicator will be displayed when the en-
gine oil pressure is below normal (10 psi or lower). If the Oil
Pressure Indicator comes on during normal operation, stop
the forklift, follow proper shut down procedures, tag forklift
with “Do Not Operate” tags, and have a qualied mechanic
service or repair the forklift BEFORE placing it into service
again.
E. LOW COOLANT LEVEL
The Low Coolant Level Indicator will be displayed when the
coolant level in the surge tank drops below normal. Add
coolant to the top of the sight gauge of the surge tank.
F. WAIT TO START
The Wait to Start Indicator is displayed when the key switch is
moved to the RUN position. Wait until the indicator goes out
before starting the engine.
G. ENGINE SERVICE REQUIRED
The Engine Service Required Indicator will be displayed when
a maintenance interval has been exceeded.
H. REGENERATION MENU
Pushing the soft button adjacent to the Regen Menu indica-
tor displays the exhaust system regeneration mode with the
available options.
