- 10 -
Technical specifications
Type of construction
2½-way bass reflex box which is
mechanically adjustable in four different
modes (Room-Tuning).
Tweeter is adjustable in 2 levels
Dimensions
1000 x 200 x 300 mm (Height x Width x Depth)
Weight
20,3 kg
Magnetically
shielded
No
Connectors
Gold plated/Banana plug/Pole screw
Power handling
capacity
250 W Short term IEC 268-5
150 W Long term IEC 268-5
Impedance
4-8 Ohms
