Xvive U3 User Manual

17
Tuning bandwidth
Wireless signal range
Audio frequency response
Dynamic range
Battery life
RF sensitivity
Total harmonic distortion
RF output power
Operating temperature range
Channel count
Charging voltage and current
2400 – 2483.5 MHz
Up to 90 ft.
(actual range depends on RF signal absorption, reection and interference)
20 Hz – 20 kHz (-3dB), dependent on microphone type / input signal
110 dB
Up to 5 hours
-88 dBm
0.2%
10 mW E.I.R.P. max
-18ȭ to 57ȭ (battery characteristics may limit this range)
Up to 6 channels (and U3 sets) can be used simultaneously
5V 2A
SPECIFICATIONS
U3 MICROPHONE WIRELESS SYSTEM

Xvive U3 Specifications

General

Frequency Response	20Hz - 20kHz
Latency	<5ms
Battery Life	Up to 5 hours
Frequency Band	2.4 GHz
Dynamic Range	110dB
Type	Digital Wireless Microphone System
Channels	6
Audio Output	Balanced XLR
Operating Range	Up to 30 meters
