2 Product Description
2.1 General description
The package
The package includes:
• Level transmitter unit sensor
• Cable holder
About the level sensor
The level sensor is designed for submerged measuring of liquid levels in open channels,
drains, or tanks.
Operating in both clean, and heavily polluted, viscous
fluids, suitable applications include
pump stations, sewage plants, waterworks, and industrial process tanks.
Signal output is a standard 4–20 mA direct current, proportional to the measured level.
Features
• Durability and high resistance to grime, deposits, and chemicals due to seamless
encapsulated design, and choice of materials
• 2–wire 4–20 mA, passive signal cable with pressure equalizing tubing
• Steel reinforced cable provides tensile strength.
• Cable lengths for the standard measuring ranges: 12 m (39.37 ft) cable for 0–3 m (0–
98.4 ft), 0–5 m (0–16.4 ft), and 0–10 m (0–32.8 ft) ranges.
Available languages
For manuals in other languages, visit http://tpi.xyleminc.com.
2.2 Approvals and standards
CE conformity
Directive Description
The EMC directive In accordance with EN 61000-6-1:1999, EN 61000-6-2:1999,
EN 61000-6-3:2001, EN 61000-6-4:2001
Ingress protection rating IP 68
2.3 Wiring and parts
Wiring
Wire color Description
Red or white Power + 10–30 V DC
Brown Signal/4 - 20 mA
Black Signal ground/shield (P/E connection)
