7 Technical Reference
7.1 Dimensions
1 2
3
4
WS009999A
1. 60 mm (2.4 in)
2. 53 mm (2.1 in)
3. 116 mm (4.6 in)
4. 86 mm (3.4 in)
7.2 Environmental requirements
Parameter Value
Operating temperature -20°C to +60°C (-4°F to 140°F)
Operating humidity Relative humidity, non-condensing: 85%
7.3 IP-rating
IP 20
7.4 Electrical data
Parameter Value
Supply voltage 24 V AC or DC
Frequency 45 Hz to 65 Hz
Supply voltage tolerance ±10%
Supply dropout 50 ms without function disruption
Four relays 5 A, 250 VAC, normally opened
Power consumption 24 VDC maximum: 3 VA
24 VAC maximum: 6 VA
7.5 Approvals
• CE
• CSA/US
