XYZ Machine Tools SMX 2500 User Manual

132
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Parts List - SMX2500 - Upper Vari-Disc Drive Sub-Assembly (Figure 51)
ITEM
P/N
DESCRIPTION
QTY
1
VS42
FRU-K3-SPINDLE PULLEY BEARING HOUSING
1
2
VS43
FRU-K3-BALL BEARING 6012ZZ
1
3
VS44
FRU-K3-ADJUSTABLE-DRIVEN VARIDISC
1
4
VS36
FRU-K3-SPEED CHANGE PLATE
1
5
VS38
FRU-K3-WASHER M5-P0.8x20L
2
6
VS37
FRU-K3-PIVOT SLEEVE Ø 5
2
7
VS123
FRU-K3-SCREW-SHCS M5-0.8X20L
2
8
VS39
FRU-K3-SPEED CHANGE PLATE PIVOT STUD
1
9
VS41
FRU-K3-WASHER Ø 8.2
1
10
VS40
FRU-K3-ROLL PIN Ø3x15L
2
11
VS35
FRU-K3-ADJUSTMENT NUT
1
12
VS34
FRU-K3-CHAIN END STUD
1
13
VS33
FRU-K3-CHAIN FRONT SCREW M4-P0.7x5L
1
14
24564
BEARING HOUSING ASSEMBLY
1
i00696-K2-K3
