Specifications
DVD Player
Frequency response: 10Hz-20kHz
Channel separation @ 1kHz: >65dB
D/A converter: 24 Bit
FM Tuner
Tuning range: 87.5MHz-108MHz
Usable sensitivity: 8.5dBf
50dB quieting sensitivity: 10dBf
Stereo separation @ 1kHz: 40dB
Frequency response: 30Hz-13kHz
AM Tuner
Tuning range: 522MHz-1611MHz
Usable sensitivity: 22dBuV
Frequency response: 50Hz-2.2kHz
Monitor
Panel size: 17,8 cm/7’’ diagonal measurement
View angle (up/down/left/right): 30/60/60/60°
Resolution: 480 W x 234 H
Brightness (cd/m2): 350
Contrast ratio: 300:1
LCD Elements: 336,960
General
Operating voltage: 11-16 VDC, negative ground
Speaker output impedance: 4~8 ohms
Line output voltage: 2 Volts
Line output impedance: 200 ohms
Chassis dimensions: 7" x 7" x 2", (178 x 178 x 51 mm)
34
CEA-2006 Power Standard Specifications
(reference: 14.4VDC +/- 0.2V, 20Hz~20kHz)
Power Output: 17 Watts RMS x 4 channels at 4 ohms and < 1% THD+N
Signal to Noise Ratio: 80dBA (reference: 1 watt into 4 ohms)
Specification and design of this model is necessarily subject to changes without notice.
If at any time in the future you should need to dispose this product please note
that waste electrical products should not be disposed with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer
for recycling advice (Waste Electrical and Electronic Equipment Directive).
This unit is manufactured under license from Dolby Laboratories. “Dolby”, “Pro
Logic II”, and the double - D symbol are trademarks of Dolby Laboratories.
