SPECIFICATIONS
Circuit : Grounded Grid Class B
Frequency Coverage : Ham bands 80 through 10 meters
Plate Input : 1200 Watts PEP, 1000 Watts CW and 600 Watts AM
Plate voltage : 2400 Volts DC
Drive Requirement : 100 Watts PEP
Input Impedance : 50 ohms, unbalanced
Output Impedance : 50 - 75 ohms, unbalanced
Third Order Distortion : 30 db or better at 1000 Watts PEP
Tube Complement : 2 x 572B/T160
Cooling : Forced-air cooling
Power Requirements : AC 100, 1 10 Volts 50/60Hz 17 Amps
AC 200, 220, 230 Volts 50/60Hz 9 Amps
Dimensions : 14
1/2
" Wide, 6
1/4
" High, 11
1/2
" Deep
Weight : 44 Ibs
FRONT PANEL CONTROLS
POWER - OFF : Rocker switch turns power on
OPER - TUNE. : Rocker switch applies Bias when standby and relay
is disengaged.
SWR - IP : Rocker switch selects either SWR or plate current
meter reading.
F - R : Rocker switch selects either forward or reflected
SWR bridge reading.
SENS : Potentiometer adjusts meter sensitivity for SWR
measurement.
PLATE : Plate capacitor in tank circuit.
INSTALLATION
The FL-2000B has been designed incorporating two safety locks to prevent
dangerous high voltage shock. However, extreme care is recommended when
servicing inside the cabinet
.
