Page 95FT-450D OPERATION MANUAL
I NSTALLATION OF O PTIONAL A CCESSORIES
MOUNTING BRACKET MMB-90 INSTALLATION
The MMB-90 is a mounting bracket designed to match the YAESU FT-450D transceiver.
Parts List
Mounting Bracket ........................................................ 1 pc
Double Face Adhesives ............................................ 2 pcs
Screws, Washers & Nuts for Mounting Bracket
M4 Knob-screws .................................................. 4 pcs
M5X20 Screws ..................................................... 4 pcs
M5X20 Tapping screws ........................................ 4 pcs
Washers ............................................................... 8 pcs
Washers ............................................................... 4 pcs
N5 Nut .................................................................. 4 pcs
Installation Procedure
1. Determine a convenient mounting location with
sufficient clearance and ventilation. Use the
bracket as a template and locate the mounting
holes. Use a 4.8-mm (3/16#) bit to drill the holes.
Secure the bracket with the supplied screws,
washers and nuts.
NOTE:
The supplied double-sided adhesive tape may be
used to temporarily hold the mobile mounting
bracket in place, while drilling the holes for instal-
lation.
Stay (user prepared)
2. Position the transceiver in the bracket so the holes
in the side are aligned with those in the bracket.
Fasten the transceiver into place using the sup-
plied Knob-screws (M4).
Upper side
Lower side
M4 Knob-screws
(4 pcs)
