Table 1. Parameter Values (Dash Display Software v3.0)
Parameter Function Range Default
TOP SPEED FWD Max speed forward. 0.5 to 7.2 mph 7.1 mph
TOP SPEED REV Max speed reverse. 0.5 to 7.2 mph 7.1 mph
ACCEL MODE (1 − 4) Percent of maximum
acceleration.
Only limited by
preceding modes.
4 = 100% 3 = 80% 2 =
70% 1 = 60%
AUTO DECEL AKA neutral or release
braking.
30-100; 1 = 0.1 seconds 30 (3 seconds)
PLUG DECEL AKA regen braking.
Controls plugging regen
strength in deceleration
time to go from 100 to
0%.
3-100; 1 = 0.1 seconds 14 (1.4 seconds)
LIFT ACCEL Time to ramp up pump
motor from 0 to 100%
(slope).
3-100; 1 = 0.1 seconds 3 (0.3 seconds)
MAX LIFT SPEED Max motor speed in Hz. 6 to 100% 100%
MAX LOWER SPEED Maximum current to
lowering prop valve.
0-100% of 1.7 Amps 54.9 (0.93 Amps)
TILT SPEED FREE Adjusts pump motor
speed and current to
Aux prop valve when
mast prox sw is ON.
6 to 30% of max speed 27%
TILT SPEED MAIN adjusts pump motor
speed and current to
Aux prop valve when
mast prox sw is OFF.
6 to 30% of max speed 15%
SIDE SHIFT SPEED Adjusts pump motor
speed and current to
Aux prop valve when SS
is requested.
6 to 50% of max speed 19%
4TH AUX IN SPEED Adjusts pump motor
speed and current to
Aux prop valve when 4th
function is requested.
6 to 30% of max speed 10%, depends on 4th
type selected. 3 - No 4th
function.
NOTE: Certain lift truck models are not capable of operating at the Max range allowed by the Dash Display. If a parameter
value higher than the truck's ability is entered, the value will revert to the maximum allowed for that lift truck.
2200 YRM 1415 Parameters
