Table 2. Parameter Values (Dash Display Software v3.02)
Parameter Function Range Default
TOP SPEED FWD Max speed forward. 0.5 to 7.2 mph 7.1 mph
TOP SPEED REV Max speed reverse. 0.5 to 7.2 mph 7.1 mph
ACCEL MODE (1 − 4) Percent of maximum ac-
celeration.
Only limited by preced-
ing modes.
4 = 100% 3 = 80% 2 =
70% 1 = 60%
AUTO DECEL AKA neutral or release
braking.
0.3-10 seconds 3 seconds
PLUG DECEL AKA regen braking.
Controls plugging regen
strength in deceleration
time to go from 100 to
0%.
0.3-10 seconds 1.4 seconds
LIFT ACCEL Time to ramp up pump
motor from 0 to 100%
(slope).
0.3-10 seconds 0.3 seconds
MAX LIFT SPEED Max motor speed in %. 6 to 100% 100%
MAX LOWER SPEED Maximum current to low-
ering prop valve.
0-100% of 1.7 Amps 54.9 (0.93 Amps)
TILT SPEED FREE Adjusts pump motor
speed and current to
Aux prop valve when
mast prox sw is ON.
6-30% of max speed 27%
TILT SPEED MAIN Adjusts pump motor
speed and current to
Aux prop valve when
mast prox sw is OFF.
6-30% of max speed 15%
TILT VALV ACC Sets tilt valve solenoid
opening time (ramp up).
0.0-5 seconds 0.3 seconds
TILT VALV DEC Sets tilt valve solenoid
closing time (ramp
down).
0.0-5 seconds 0.8 seconds
NOTE: Certain lift truck models are not capable of operating at the Max range allowed by the Dash Display. If a parameter
value higher than the truck's ability is entered, the value will revert to the maximum allowed for that lift truck.
2200 YRM 1415 Parameters
5
