Legend for Figure 2
1. NAMEPLATE
2. WARNING DECAL
3. PATENTS AND TRADEMARKS LABEL
4. FORK WARNING LABEL
5. OPERATING MANUAL
6. YALE BLACK DECAL
7. WARNING LABEL
8. BATTERY DISCHARGE NOTICE LABEL
9. MOVING MAST LABEL
10. MANUAL LOWERING LABEL
Major Components of Lift Truck
Figure 3, Figure 4, Figure 5, Figure 6, and Figure 7 show
the major components of the lift truck.
Model Description
11
